Perfusor Space

Perfusor^® Space is a syringe infusion pump that can be used to configure customized, tailor-made solutions as individual pumps, small therapy units, or a complex infusion system.The small, light and intuitive configuration of the pump provides a user-friendly solution to complex therapies, integrating all clinical areas into one system.B. Braun Space can also be integrated into the data communications network of every advanced hospital operation.

Perfusor Space

Product Details

Features

Light weight pump (1.4kg) and reliable battery duration of 8 hours on a 25 ml/h rate
Automatic syringe size recognition and compatible withsyringes 2/3 ml, 5/6 ml, 10/12 ml, 20 ml, 30/35 ml and 50/60ml.
Therapy Profiles available : Dose Rate Calculation, DoseOver Time, Ramp and Taper Mode, Program Mode,Intermittent Mode, PCA, TCI, TIVA, KVO and Take Over Mode
Syringe holder with integrated piston break, protecting againstfree flow
Automatic drive technology
Automatic bolus reduction function triggered by occlusionalarm
Drug Library with capacity to up to 1200 drug names,including therapy data, information and up to 10concentrations per drug to be stored in 30 differentcategories. Drug information can be subdivided in 50 caeunits and up to 16 Patient Profiles.

Technical Specifications

Type of Unit	Syringe Driven Infusion Pump
Dimensions	249 x 68 x 152 mm (WxHxD), drive parked
Weight	Approx. 1.4 kg
Moisture protection	IP 22, drip protected for horizontal usage
Display	Backlit graphic display, ~40° read angle from allsides
Keypad	Backlit keys, cell phone like cursor navigation
Flow Rates	0.01-1800 ml/h
Accuracy of set delivery rate	<< ± 0,5 % mechanical accuracy ± 2 % in compliance with IEC/EN 60601- 2-24
Operating Temperature	+5° C … + 40° C, +41° F …. +105 °F
Voltage	11 – 16 V DC supplied by external Space Power Supply or by SpaceStation
Battery operating time	Minimal power consumption of the devices and new battery technology ensure long operating times, e.g. 16.8 hrs @ 1 ml/h, 16 hrs @ 5 ml/h, 14 hrs @ 20 ml/h
Lifetime	Min. 10 years under continuous duty conditions
